LEDs
(20) Fixed green LED: hoist is active.
Flashing green LED: hoist is active
with automatic rope movement
enabled (AWC).
(23) Fixed yellow: warning due to three
possible causes:
- max. geometric configuration
reached.
- close to the max. crane
performance limit.
- stabiliser not set on to the
ground.
For further information about the
warnings present, go to the menu
(F3).
(21) Fixed yellow LED: HSS is active.
(22) Blinking green: automatic max.
speed reduction during the
operation.
(24) Fixed red: alarms.
For further information about the
alarms present, go to the menu
(F3).
Buttons for the display (Z)
Arrow keys to move
inside the display (move
between options, select
new pages).
ESC button:
exit any page.
ENTER
button:
confirm button.
Multifunctional button: push to access data.
• F1: Settings
• F2: Visualisations
• F3: Warnings/Alarms
• F4: Oil temperature and fan(s) speed
Locking the controller:
Push the emergency button.
Unlocking the controller:
1. Release the emergency button.
2. Push and hold for at least two seconds the button (2) to activate the controller. The lights (3)
will turn on.
The control system
EFFER 265-315-395-525 Progress 2.0 CE 67
