ESIM384 Installation and Conguration Manual v1.1
Enable keypad
partition switch
EKB2
Menu path:
OK → iiii → OK → PRIMARY SETTINGS → OK → KEYPAD PARTITION → OK → PARTITION SWITCH
→ OK → ENABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 77 and parameter status value:
77 1#
Example: 771#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Disable keypad
partition switch
EKB2
Menu path:
OK → iiii → OK → PRIMARY SETTINGS → OK → KEYPAD PARTITION → OK → PARTITION SWITCH
→ OK → DISABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 77 and parameter status value:
77 0 #
Example: 770#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
NOTE: Keypad partition switch can only be used when the system is partitioned.
23.4. User/Master Code Partition
User/master code partition determines which system partition (-s) can be armed/disarm using a certain user/master code. User/master
code must be assigned to the same partition as the keypad (see 23.3. Keypad Partition and Keypad Partition Switch) in order to arm/
disarm the system by EKB2/EKB3/EKB3W/EWKB4 keypad . For more details on system arming/disarming by the keypad, please refer to
12.3. EKB2 Keypad and User/Master Code, 12.4. EKB3 Keypad and User/Master Code and 12.5. EKB3W/EWKB4 Keypad and
User/Master Code.
Set user/master
code partition
EKB2
Menu path:
Master code: OK → mmmm → OK → CODES → OK → MASTER CODE → OK → PARTITION → OK
→ pv → OK
User code 2... 17: ... → CODES → OK → USER CODE (2-17) → OK → USER CODE 2... 17 → OK →
PARTITION → OK → pv → OK
User code 18... 30: ... → CODES → OK → USER CODE (18-30) → OK → USER CODE 18... 30 → OK
→ PARTITION → OK → pv → OK
Value: mmmm – 4-digit master code; pv – partition value, range – [01... 15].
EKB3/
EKB3W/
EWKB4
Press , 5, enter 01/user code slot, partition value and master code:
Master code:
5 01 pv mmmm #
User code:
5 us pv mmmm #
Value: us - user code slot, range - [02... 30]; pv – partition value, range – [01... 15]; mmmm -
4-digit master code.
Example:
504081111#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
NOTE for EKB3/EKB3W/EWKB4: The Conguration mode must be deactivated, while managing user and master code partition.
