ESIM384 Installation and Conguration Manual v1.1
19.2. Wireless Device Information
Once a wireless device is paired, the user can view the following information of a determined wireless device:
• Battery level (expressed in percentage).
• Wireless signal strength (expressed in percentage).
• Error rate (number of failed data transmission attempts in 10-minute period) - indicated only in EKB2 keypad menu.
• Firmware version.
• Test Time period (expressed in milliseconds) of a wireless device - indicated only in SMS text message reply.
To view the wireless device information, please refer to the following conguration methods.
View wireless device
information
SMS
SMS text message content:
ssss_RFINFO:wless-id or ssss_RFINFO:Znn
Value: ssss – 4-digit SMS passwordwless-id – 8-character wireless device ID code; nn –
wireless zone number, range – [13... 80].
Example: 1111_RFINFO:535185D
EKB2
Menu path:
Battery level: OK → iiii → OK → WIRELESS DEVICES 1... 2→ OK → wless-dev wless-id → OK
→ BATTERY
Wireless signal: ... → wless-dev wless-id → OK → SIGNAL
Error rate: ... → wless-dev wless-id → OK → ERROR RATE
Firmware version: ... → wless-dev wless-id → OK → FW RELEASE
Value: iiii – 4-digit installer code; wless-dev – wireless device model; wless-id – 8-character
wireless device ID code.
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
The system supports up to 32 wireless devices. To view the number of available wireless device slots in the system, please refer to the
following conguration methods
View available
wireless device slots
SMS
SMS text message content:
ssss_STATUS_FREE
Value: ssss – 4-digit SMS password.
Example: 1111_STATUS_FREE
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
19.3. Wireless Signal Status Monitoring
If the wireless signal is lost due to poor signal strength or low battery power on a certain wireless device and does not restore within
4-hour period, the system will cause an alarm (by default, the alarm is disabled). This event is identied as Wireless Signal Loss. By default,
indicated as No wireless signal from wless-dev wless-id Tamper x in the SMS text message (wless-dev = wireless device model; wless-id =
8-character wireless device ID code; x = tamper number). The user will also be notied by SMS text message as soon as the wireless signal
is restored.
The default period for wireless signal loss detection is 4 hours. However, a custom wireless signal loss timeout can be set up that must be
at least 3 times longer than the longest Test Time period of a wireless device currently paired with the system. In addition, ELDES Congu-
ration software indicates a timer of the last Test Time signal delivered by a paired and unpaired wireless device. The software will also warn
you if the delivery of the Test Time signal is delayed for a time period that is 5 minutes longer than the Test Time period of a paired wireless
device. In case the Test Time signal delivery of an unpaired wireless device is delayed for more than 1,5 minute, a warning will follow and
the icon of such wireless device will be removed from the software’s interface in 10 seconds.
Manage
Grade2 wireless
communication
settings
ELDES
Cong-
uration
soft-
ware
This operation may be carried out from the PC using the ELDES Conguration software.
