ESIM384 Installation and Conguration Manual v1.1
1. GENERAL INFORMATION
1.1. Functionality
ESIM384 – micro-controller based alarm system for houses, cottages, country homes, garages and other buildings, also capable of manag-
ing electrical appliances via cellular GSM/GPRS network. It can also be used as Intercom system.
Examples of using the system:
• Property security.
• Alarm switch.
• Thermostat, heating and air-conditioner control, temperature
monitoring.
• Lighting, garden watering, water pump and other electrical
equipment control via SMS text messages.
• Remote listening to what is happening in the secured area.
• Mains power status notication by SMS text message.
• Two-way intercom device via GSM network.
1.2. Compatible Device Overview
Wired Devices
Device Description Max. Connectible Devices
EKB2 LCD keypad 4*
EKB3 LED keypad 4*
EA1 Audio output module with 3,5mm jack 1**
EA2 Audio amplier module 1W 8 1**
EPGM1 16 zone and 2 PGM output expansion module 2
ELAN3-ALARM Ethernet communicator 1
EPGM8 8 PGM output expansion module 1**
Wireless Devices
Device Description Max. Connectible Devices
EW2 Wireless 2 zone and 2 PGM output expansion module 16*****
EWP2 Wireless motion detector 32***
EWP3 Wireless motion detector 32***
EWD2 Wireless magnetic door contact/shock sensor/ood sensor 32***
EWD3 Wireless magnetic door contact/shock sensor/ood sensor 32***
EWK1**** Wireless keyfob with 4 buttons 5***
EWK2**** Wireless keyfob with 4 buttons 5***
EWS3 Wireless indoor siren 32***
EWK2A**** Wireless keyfob with 1 button 5***
EWS2 Wireless outdoor siren 32***
EKB3W Wireless LED keypad 4***
EWKB4 Wireless LED keypad 4***
EWKB5 Wireless touchpad 4***
EWF1 Wireless smoke detector 32***
EWF1CO Wireless smoke and CO detector 32***
EWR2 Wireless signal repeater 4***
EWM1 Wireless power socket 32***
* - A mixed combination of EKB2 and EKB3 keypads is supported. The combination can consist of up to 4 keypads in total.
** - Only 1 of these modules can be connected at a time if the module slots are implemented in ESIM384 unit.
*** - A mixed combination of wireless devices is supported. The combination can consist of up to 32 wireless devices in total.
**** - A mixed combination of EWK1, EWK2 and EWK2A keyfobs is supported. The combination can consist of up to 5 keyfobs in total.
***** - EW2 creates 4 wireless zones, therefore the max. number of connectible EW2 devices is 16 if no keypad zones, no EPGM1 and no
virtual zones exist in the system’s conguration.
1.3. Default Parameters and Ways of Parameter Conguration
Main Settings
Parameter Default Value
Congurable by:
SMS EKB2
EKB3/
EKB3W/
EWKB4
Conguration
Software
User 1... 10 name N/A

User 1... 10 phone number N/A
   
User 1... 10 partition Partition 1
  
User 1...10 - call in case of alarm Enabled
  
Allow control from any phone number Disabled
   
SMS password 0000
   
SMS language Depends on the rmware
Partition 1 name PART1

Partition 2 name PART2

Partition 3 name PART3

Partition 4 name PART4

