ESIM384 Installation and Conguration Manual v1.1
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
ATTENTION: The system will NOT send any data to the monitoring station while remote connection, remote rmware update or remote
listening/2-way voice communication is in progress. However, during the remote connection session or remote listening/2-way voice com-
munication process, the data messages will be queued up and transmitted to the monitoring station after the remote connection session or
remote listening/2-way voice communication process is over, while during the remote rmware update process NO data will be queued up
and all data messages will be lost.
ATTENTION: Phone calls via GSM network to the listed user phone number in case of alarm are disabled by force when MS mode is enabled.
NOTE: Additional charges may apply for voice calls/data trac based on your cell phone service plan when using the MS mode.
30.1. Data Messages – Events
The conguration of data messages is based on Ademco Contact ID protocol. The data messages can either be transmitted to the monitor-
ing station alone or with duplication by SMS text message to listed user phone number. For more details on system notications by SMS text
message, please refer to 27. SYSTEM NOTIFICATIONS.
Seq. No. Event
Code
Event Description
1 1110 Fire alarm Transmitted in case a zone of Fire type is violated.
2 3110 Fire restore Transmitted in case a zone of Fire type is restored.
3 1120 Silent/Panic zone alarm Transmitted in case a zone of Silent/Panic type is violated.
4 3120 Silent/Panic zone restore Transmitted in case a zone of Silent/Panic type is restored.
5 1121 Disarmed by user (Duress
code)
Transmitted in case the system is disarmed by Duress code.
6 3121 Armed by user (Duress code) Transmitted in case the system is armed by Duress code.
7 1130 Burglary alarm Transmitted in case a zone of Delay (if not disarmed before entry delay countdown
is completed), Interior Follower or Instant type is violated.
8 3130 Burglary restore Transmitted in case a zone of Delay (if not disarmed before entry delay countdown
is completed), Interior Follower or Instant type is restored.
9 1133 24-Hour zone alarm Transmitted in case of zone of 24-Hour type is violated.
10 3133 24-Hour zone restore Transmitted in case of zone of 24-Hour type is restored.
11 1144 Tamper alarm Transmitted in case the tamper is violated.
12 3144 Tamper restore Transmitted in case the tamper is restored.
13 1146 Instant Silent zone alarm Transmitted in case of zone of Instant Silent type is violated.
14 3146 Instant Silent zone restore Transmitted in case of zone of Instant Silent type is restored.
15 1150 Report/Control zone trigger Transmitted in case of zone of Report/Control type is triggered.
16 3150 Report/Control zone restore Transmitted in case of zone of Report/Control type is restored.
17 1158 Temperature risen Transmitted in case of the temperature has increased above the MAX set value.
18 1159 Temperature fallen Transmitted in case of temperature has decreased below the MIN set value.
19 1162 CO level critical Transmitted in case the critical level 4 of carbon monoxide (CO) concentration de-
tected by EWF1CO is reached.
20 1301 Mains power loss Transmitted in case the mains power is lost.
21 3301 Mains power restore Transmitted in case the mains power is restored.
22 1302 Low battery Transmitted in case the backup battery voltage is 10.5V or lower / the wireless de-
vice battery level runs below 5%.
23 1308 System shutdown When the system is running on backup battery power, it transmits the data mes-
sage before the backup battery power is fully depleted.
24 1309 Battery failed Transmitted in case the backup battery resistance is 2 or higher.
25 1311 Battery dead or missing Transmitted in case the backup battery is not present or the battery voltage runs
below 5V.
26 3311 Battery connection restore Transmitted in case the backup battery connection is xed.
27 1321 Siren fail Transmitted in case the siren is disconnected/broken.
28 3321 Siren restore Transmitted in case the siren is connected/xed.
29 1330 Communication bus fail Transmitted in case the RS485 device, such as keypad, ELAN3-ALARM or EPGM1 is
disconnected/broken.
30 3330 Communication bus restore Transmitted in case the RS485 device, such as keypad, ELAN3-ALARM or EPGM1
is connected/xed
