2. TECHNICAL SPECIFICATIONS
2.1. Electrical and Mechanical Characteristics
Electrical and Mechanical Characteristics
Power supply 16-24V 50/60 Hz ~1.5A max / 18-24V
1,5A max
Current consumption in idle state w/o external devices connected Up to 80mA
Recommended backup battery voltage, capacity 12V; 1,3-7Ah
Recommended backup battery type Lead-Acid
Backup battery charge current Up to 500mA
Backup battery charge duration Up to 30 hours for 7Ah battery
GSM modem frequency 850/900/1800/1900MHz
Cable type for GSM/GPRS antenna connection Shielded
Number of zones on-board 8 (ATZ mode: 16)
Nominal zone resistance 5,6k (ATZ Mode: 5,6k and 3,3k)
Number of PGM outputs on-board 4
On-board PGM output circuit
1 R
OUT
Open collector output.
Output is pulled to COM
when turned ON.
Maximum commuting on-board PGM output values (combined) 4 x 30V; 500mA
BELL: Siren output when activated Connected to COM
BELL: Maximum siren output current 1A
BELL: Maximum cable length for siren connection Up to 100m (328.08ft)
BELL: Cable type for siren connection Unshielded
AUX: Auxiliary equipment power supply voltage 13,8V DC
AUX: Maximum accumulative current of auxiliary equipment 1,1A
AUX: Maximum cable length for auxiliary equipment connection Up to 100m (328.08ft)
AUX: Cable type for auxiliary equipment connection Unshielded
BUZ: Maximum current of mini buzzer 150mA
BUZ: Power supply voltage of buzzer 12V DC
BUZ: Cable type for mini buzzer connection Unshielded
Supported temperature sensor model Maxim®/Dallas® DS18S20, DS18B20
Maximum supported number of temperature sensors 8
DATA: Maximum cable length for 1-Wire communication Up to 30m (98.43ft)
DATA: Cable type for 1-Wire communication Unshielded
Supported iButton key model Maxim®/Dallas® DS1990A
Maximum supported number of iButton keys 16
Maximum supported number of keypads 4 x EKB2 / EKB3
Y/G: Maximum cable length for RS485 communication Up to 100m (328.08ft)
Y/G: Cable type for RS485 communication Unshielded
MIC: Maximum cable length for microphone connection Up to 2m (6.56ft)
MIC: Cable type for microphone connection Unshielded
Wireless band ISM868
Wireless communication range Up to 3000m (9842.6ft) in open areas
Maximum supported number of wireless devices 32
Event log size 1024 events
Maximum supported number of zones 80
Maximum supported number of PGM outputs 48
Cable type for zone and PGM output connection Unshielded
Generated PSTN line values Voltage: 48V; current: 25mA; impedance: 270
Communications SMS, Voice calls, GPRS network, CSD, PSTN, Ethernet via ELAN3-ALARM
Supported protocols Ademco Contact ID, EGR100, Kronos, Cortex SMS, SIA IP
Dimensions 140x100x18mm (5.51x3.94x0.71in)
Operating temperature range -20...+55°C (-4... +131°F)
Humidity 0-90% RH @ 0... +40°C (0-90% RH @ +32... +104°F)
(non-condensing)
