ESIM384 Installation and Conguration Manual v1.1
d) Run ELDES Conguration software.
e) Select the newly replaced temperature sensor ID from the drop-down list of the temperature sensor slot that was previously associated
with a faulty temperature sensor.
Remove/replace
individual
temperature sensor
ELDES
Cong-
uration
soft-
ware
This operation may be carried out from the PC using the ELDES Conguration software.
24.2. Primary and Secondary Temperature Sensors
Any out of 8 available temperature sensors can be set as primary or secondary. The real-time temperature values of the primary and sec-
ondary temperature sensors are included in the Info SMS text message (see 26. SYSTEM INFORMATION. INFO SMS) as well as the tem-
perature measured by the primary temperature sensor is indicated in the home screen view of EKB2 keypad.
To set temperature sensors as primary or secondary, please refer to the following conguration methods.
Set primary
temperature sensor
SMS
SMS text message content:
ssss_TEMPI:PRIM:ts
Value: ssss – 4-digit SMS password; ts – temperature sensor slot, range - [1... 8].
Example: 1111_TEMPI:PRIM:4
EKB2
Menu path:
OK → iiii → OK → PRIMARY SETTINGS → OK → TEMP SENSORS → OK → PRIMARY TEMP SENS
→ OK → 1... 8 CONNECTED → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 89 and temperature sensor slot:
89 ts #
Value: ts – temperature sensor slot, range - [01... 08].
Example: 8903#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Set secondary
temperature sensor
SMS
SMS text message content:
ssss_TEMPI:SEC:ts
Value: ssss – 4-digit SMS password; ts – temperature sensor slot, range - [1... 8].
Example: 1111_TEMPI:SEC:3
EKB2
Menu path:
OK → iiii → OK → PRIMARY SETTINGS → OK → TEMP SENSORS → OK → SECOND. TEMP SENS
→ OK → 1... 8 CONNECTED → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 90 and temperature sensor slot:
90 ts #
Value: ts – temperature sensor slot, range - [01... 08].
Example: 9005#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
To view the slot number of primary and secondary temperature sensors, please refer to the following conguration methods.
