ESIM384 Installation and Conguration Manual v1.1
EKB2
Menu path:
On-board zone: OK → iiii → OK → ZONES → OK → ONBOARD ZONES → OK → ZONE 1... 16 → OK
→ STATUS → OK → ENABLE → OK
Wireless zone: OK → iiii → OK → WIRELESS ZONES → OK → WIRELESS ZONES 1... 4 → OK →
WIRELESS ZONE 13... 80 → OK → STATUS → OK → ENABLE → OK
Keypad zone: OK → iiii → OK → ZONES → OK → KEYPAD ZONES → OK → 1ST... 4TH KEYPAD
ZONE → OK → STATUS → ENABLE → OK
EPGM1 zone: ... → EPGM1 ZONES 1-16... EPGM1 ZONES 17-32 → OK → 1... 8. EPGM1 ZONE 1...
32 → OK → STATUS → ENABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 52, zone number and parameter status value:
52 nn 1 #
Value: nn – zone number, range – [01... 80].
Example: 52151#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
14.10. Viewing Zone State
The zone state (violated/restored) is indicated in real-time by all available conguration methods. However, the most convenient way to
view the zone state is using the graphical interface of ELDES Conguration software as follows:
• Red-zoneisviolated.
• Green-zoneisrestored.
• Grey-zoneisdisabled.
To view the zone state, please refer to the following conguration methods.
View zone state
SMS
SMS text message content:
ssss_INFO
Value: ssss – 4-digit SMS password.
Example: 1111_INFO
EKB2
Menu path:
OK → uumm → OK → VIOLATED ZONES → OK → ZONE 1... 80
Value: uumm – 4-digit user/master code.
EKB3/
EKB3W/
EWKB4
Please, refer to illuminated zone indicators ranging from 1 through 12 on the keypad. The
ashing indicator
represents violated high-numbered zones (Z13-Z80). For more details
on violated high-numbered zone indication, please refer to 29. INDICATION OF SYS TEM
FAULTS.
