ESIM384 Installation and Conguration Manual v1.1
Disable EPGM8 mode
EKB2
Menu path:
OK → iiii → OK → USING EPGM8 → OK → DISABLE → OK
Value: iiii – 4-digit installer code.
EKB3/
EKB3W/
EWKB4
Enter parameter 33 and parameter status value:
33 0 #
Example: 330#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
18.3. PGM Output Names
Each PGM output has a name that can be customized by the user. Typically, the name species a device type connected to a determined
PGM output, for Example: Lights. The name can be used instead of PGM output number when controlling the PGM output by SMS text
message. By default, the PGM output names are: C1 – Controll1, C2 – Controll2, C3 – Controll3, C4 – Controll4 etc.
Set PGM output name
SMS
SMS text message content:
ssss_Coo:out-name
Value: ssss – 4-digit SMS password; oo – PGM output number, range – [1... 80]; out-name –
up to 16 characters PGM output name.
Example: 1111_C2:Lights
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
View PGM output
names
SMS
SMS text message content:
ssss_INFO
Value: ssss – 4-digit SMS password.
Example: 1111_STATUS
EKB2
Menu path:
OK → mmmm → OK → PGM OUTPUTS → OK → out-name
Value: mmmm – 4-digit master code; out-name – up to 16 characters PGM output name.
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
ATTENTION: Space, colon, semi-colon characters, parameter names and/or values, such as PSW, STATUS, ON, OFF etc. are NOT allowed in
PGM output names.
18.4. Disabling and Enabling PGM Outputs
By default, all PGM outputs are enabled. Once a PGM output is disabled, it can be turned ON or OFF thus the change will not be seen neither
on the EKB2 keypad nor via Cloud platform. To disable/enable a certain PGM output, please refer to the following conguration method.
Disable/enable PGM
outputs
ELDES
Cong-
uration
softwarel
This operation may be carried out from the PC using the ELDES Conguration software.
18.5. Turning PGM Outputs ON and OFF
By default, all PGM outputs are turned OFF. To instantly turn ON/OFF an individual PGM output and set its state to ON/OFF when the system
starts-up, please refer to the following conguration methods.
