ESIM384 Installation and Conguration Manual v1.1
29. INDICATION OF SYSTEM FAULTS
The system comes equipped with self-diagnostic feature allowing to indicate the presence of any system fault by the keypad as well as by
SMS text message notication to the listed user phone number. By default the indication for all system faults is indicated on the keypad.
To disable/enable the indication of a certain system fault, please refer to the following conguration method.
Disable/enable
individual system fault
indication on keypad
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
ATTENTION: After enabling/disabling a certain system fault indication, it is necessary to restart the system locally by powering down and
powering up the system the system or remotely (see 34. REMOTE SYSTEM RESTART).
EKB2
icon displayed in home screen view indicates presence of system and/or EWM1 device faults. In order to view the currently
present system faults, please enter a valid user/master code to access menu section FAULTS. The description on each system
fault is provided in the table below.
View system faults
Menu path:
OK → uumm → OK → FAULTS → OK
Value: uumm – 4-digit user/master code.
Name Description
MAIN POWER LOSS Mains power is lost
LOW BATTERY Low backup battery power - backup battery voltage is 10.5V or lower
BATTERY DEAD/MISS Backup battery is not present or the battery voltage runs below 5V
BATTERY FAILED Backup battery requires replacement - backup battery resistance is 2 or higher
SIREN FAILED Wired siren is disconnected/broken
VIOLATED TAMPER One or more tampers are violated
DATE/TIME NOT SET Date/time not set
GSM CONNECT FAILED GSM connection is lost
GSM ANTENNA FAILED GSM/GPRS antenna is disconnected/broken
WLESS ANTENNA FAIL Wireless antenna is disconnected/broken
COMM BUS FAILED RS485 device, such as keypad, ELAN3-ALARM or EPGM1 is disconnected/broken
CO LEVEL CRITICAL Critical level 4 of carbon monoxide (CO) concentration detected by EWF1CO is reached
EWM1 FAULT One or more EWM1 device faults exist - enter this menu item to view the existing EWM1
device faults.
WLESS BATT LOW Low wireless device battery power - battery level is running below 5%
RF JAMMER DETECTED Wireless signal is blocked by jammer
MS COMM. FAILED Communication with monitoring station failed
Alternatively, existing EWM1 device faults can be viewed by accessing menu section FAULTS of the PGM output associated
with a certain EWM1 device.
View EWM1 faults
Menu path:
OK → mmmm → OK → PGM OUTPUTS → OK → out-name → OK → FAULTS → OK
Value: mmmm – 4-digit master code; out-name - PGM output name associated with a
certain EWM1 device.
Name Description
OVERVOLTAGE Voltage has increased above 260VAC
UNDERVOLTAGE Voltage has dropped below 190VAC
OVERCURRENT Current has increased above 12,5A
RELAY FAULT Unable to power up the appliance due to faulty relay
TEMP. FAULT Environmental temperature has dropped below -35°C (-31°F) or increased above
+90°C (+194°F)
In order to clear the existing faults, please press the
button on EWM1, turn OFF the electrical appliance or turn OFF the
wireless PGM output associated with EWM1. For more details on EWM1 device, please refer to 19.9. EWM1 - Wireless Power
Socket.
