ESIM384 Installation and Conguration Manual v1.1
EKB2
Menu path:
Real-time power consumption: OK → mmmm → OK → PGM OUTPUTS → OK → out-name →
OK → REAL TIME ENERGY
Today’s power consumption: ... → out-name→ OK → TODAY ENERGY
Monthly power consumption: ... → out-name → OK → MONTHLY ENERGY
Value: mmmm – 4-digit master code; out-name - PGM output name associated with a
certain EWM1 device.
ELDES
Cong-
uration
soft-
ware
This operation may be carried out from the PC using the ELDES Conguration software.
Reset power
consumption counter
for individual EWM1
device
SMS
SMS text message content:
ssss_EWM1RESET:out-name
Value: ssss - 4-digit SMS password; out-name - PGM output name associated with a certain
EWM1 device.
Example: 1111_EWM1RESET:Controll14
EKB2
Menu path:
OK → mmmm → OK → PGM OUTPUTS → OK → out-name → OK → RESET COUNTER → OK →
YES → OK
Value: mmmm – 4-digit master code; out-name - PGM output name associated with a
certain EWM1 device.
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Reset power
consumption counter
for all EWM1 devices
simultaneously
SMS
SMS text message content:
ssss_EWM1RESET:ALL
Value: ssss - 4-digit SMS password.
Example: 1111_EWM1RESET:ALL
NOTE: Real-time power consumption value is NOT included in the power consumption report requested by SMS text message and can only
be seen on Eldes Cloud.
19.10. EWKB5 Wireless Touchpad Overview
EWKB5 is a wireless accessory equipped with a 4.3” true-colour touch screen and compatible with ESIM384 alarm system.
device features:
• Arming and disarming
• Violated zone bypass and bypassed zone activation
• PGM output control
• Customizable user-friendly graphical menu
• Navigation through the menu using the touch screen
• Multilingual voice-guided audio instructions
• Adjustable brightness and volume level
• Battery or externally-powered
• Add/delete/edit username and user/master code PIN (accessi-
ble from the User’s menu)
EWKB5 has 1 built-in zone terminal, which is by default designed for passive wired digital sensor connection, such as magnetic door con-
tact, and 2 tamper switches for enclosure state supervision in case it is illegally opened or detached from the wall. Regardless if the tamper
switch alone is to be used, the zone must be enabled and the resistor of 5,6k nominal must be connected across Z1 and COM connectors.
It is possible to connect up to 4 EWKB5 devices to the alarm system ESIM384. The maximum wireless connection range is 1000m (~984ft)
(in open areas).
Main menu features:
Partition button – arms/disarms the system once a valid master/user code PIN is entered; indicates partition status (armed/disarmed),
presence of system faults.
Quick arm button – arms the system by touching and holding this button; master/user code not required (customizable, hidden by default;
not shown in picture).
Bypass - the Bypass icon will be shown on the main screen if any bypassed zone is present.
Fire – instantly causes re alarm by pressing and holding this button (customizable, hidden by default).
Panic – instantly causes silent alarm by pressing and holding this button (customizable, hidden by default).
Controls – opens PGM output menu, thus letting you turn a certain PGM output ON or OFF (customizable, hidden by default).
Settings – grants access to settings menu once a valid master code is entered.
