ESIM384 Installation and Conguration Manual v1.1
31 1344 RF jammer detected Transmitted in case the wireless signal is blocked by jammer.
32 3344 RF jamming stopped Transmitter in case the wireless signal is restored after jamming.
33 1354 Communication with MS failed
Transmitted in case the system ends up with all unsuccessful attempts by all
connections to deliver data message to the monitoring station. This event can be
managed using ELDES Conguration software only.
34 3354 Communication with MS
restored
Transmitted in case the system has successfully delivered the data message
to the monitoring station within the repeated data delivery cycle initiated after
Delay after last communication attempt time has expired. This event can be man-
aged using ELDES Conguration software only.
35 1358 GSM connection failed Transmitted in case the GSM connection is lost.
36 3358 SMS sending limit removed Transmitted in case the SMS text message limit is removed by user or automatically
after the set period of time has come.
37 1358 SMS sending limit reached Transmitted in case the SMS text message limit is reached.
38 1359 GSM/GPRS antenna fail Transmitted in case the GSM/GPRS antenna is disconnected/broken
39 3359 GSM/GPRS antenna restore Transmitted in case the GSM/GPRS antenna is connected/xed.
40 1360 IP connection failed
Transmitted in case the GPRS connection or Ethernet connection via ELAN3-
ALARM is lost.
41 1380 CO sensor lifetime exceeded Transmitted in case the lifetime of EWF1CO built-in CO sensor is expired.
42 1381 Wireless signal loss Transmitted in case the connection with any wireless device is lost.
43 3381 Wireless signal restore Transmitted in case the connection with any wireless device is restored.
44 1401 Disarmed by user Transmitted in case the system is disarmed by user/master code, wireless keyfob,
iButton key, SMS text message, free of charge phone call, ELDES Cloud Services, EL-
DES Conguration software, EGR100 middle-ware or Arm-Disarm by Zone method.
45 3401 Armed by user Transmitted in case the system is armed by user/master code, wireless keyfob,
iButton key, SMS text message, free of charge phone call, ELDES Cloud Services, EL-
DES Conguration software, EGR100 middle-ware or Arm-Disarm by Zone method.
46 1403 Disarmed automatically Transmitted in case the system is disarmed automatically according to scheduled
time.
47 3403 Armed automatically Transmitted in case the system is armed automatically according to scheduled time.
48 1412 Conguration via remote
connection started
Transmitted in case the remote connection session is opened.
49 1441 Disarmed in Stay mode Transmitted in case the system is disarmed in Stay mode.
50 3441 Armed in Stay mode Transmitted in case the system is armed in Stay mode.
51 3456 Armed by user (partial arm) Transmitted in case the system is armed, while violated zone (-s) with Force attrib-
ute enabled exist.
52 3463 SGS code entered Transmitted in case the SGS code is entered.
53 1570 Zone bypassed Transmitted in case a violated zone is bypassed.
54 3570 Bypassed zone activated Transmitted in case a bypassed zone is activated.
55 3602 Test event/Kronos ping Transmitted for system online status verication purposes.
56 3626 Date/time not set Transmitted in case system date and time is not set.
57 1900 System started Transmitted on system startup.
The following table refers to user IDs included in arm/disarm data messages.
Type ID Type ID Type ID
User Phone Number 1 0 iButton 7 16 User Code 7 32
User Phone Number 2 1 iButton 8 17 User Code 8 33
User Phone Number 3 2 iButton 9 18 User Code 9 34
User Phone Number 4 3 iButton 10 19 User Code 10 35
User Phone Number 5 4 iButton 11 20 User Code 11 36
User Phone Number 6 5 iButton 12 21 User Code 12 37
User Phone Number 7 6 iButton 13 22 User Code 13 38
User Phone Number 8 7 iButton 14 23 User Code 14 39
User Phone Number 9 8 iButton 15 24 User Code15 40
User Phone Number 10 9 iButton 16 25 User Code 16 41
iButton 1 10 Master Code 26 User Code 17 42
iButton 2 11 User Code 2 27 User Code 18 43
iButton 3 12 User Code 3 28 User Code 19 44
iButton 4 13 User Code 4 29 User Code 20 45
iButton 5 14 User Code 5 30 User Code 21 46
iButton 6 15 User Code 6 31 User Code 22 47
