EN
ESIM384 Installation and Conguration Manual v1.1
Enable/disable Treat
PSTN Call as User Call
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
30.2.4. CSD
The system supports up to 5 monitoring station phone numbers for communication with the alarm system by CSD communication method.
Tel. Number 1 is mandatory, the other four can be used as backup phone numbers and are not necessary. The supported phone number
formats are the following:
• International (with plus) – The phone number must be entered starting with plus and an international country code in the following
format: +[international code][area code][local number], example for UK: +44170911XXXX1. This format can be used when setting up
the phone number by ELDES Conguration software.
• International (with 00) – The phone number must be entered starting with 00 and an international country code in the following ž
format: 00[international code][area code][local number], example for UK: 0044170911XXXX1. This format can be used when setting
up the phone number by EKB2/EKB3/EKB3W/EWKB4 keypad.
To set up the system for data transmission via CSD, please follow the basic conguration steps:
1. Enable MS Mode parameter (see 30. MONITORING STATION).
2. Set 4-digit Main Account number (see 30. MONITORING STATION).
3. Set Tel. Number 1... 5.
Set monitoring station
phone number
EKB2
Menu path:
OK → iiii → OK → MS SETTINGS → OK → CSD SETTINGS → OK → TEL. NUMBER 1... 5 → OK →
ttteeellnnuumm → OK
Value: iiii – 4-digit installer code; ttteeellnnuumm – up to 15 digits monitoring station phone
number.
EKB3/
EKB3W/
EWKB4
Enter parameter 85, number of entry and phone number:
85 ps ttteeellnnuumm #
Value: ps – phone number slot, range – [01... 05]; ttteeellnnuumm – up to 15 digits monitor-
ing station phone number.
Example: 85010044170911XXXX1#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
Delete monitoring
station phone number
EKB2
Menu path:
OK → iiii → OK → MS SETTINGS → OK → CSD SETTINGS → OK → TEL. NUMBER 1... 5 → OK → OK
Value: iiii – 4-digit installer code.
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
By default, if the initial attempt to transmit data to the monitoring station’s phone number via CSD method is unsuccessful, the system
will make up to 2 additional attempts. If all attempts are unsuccessful, the system will switch to next backup connection that follows in the
sequence and will attempt to transmit data until it is successfully delivered to the monitoring station.
Set attempts
EKB2
Menu path:
OK → iiii → OK → MS SETTINGS → OK → CSD SETTINGS → OK → ATTEMPTS → OK → at → OK
Value: iiii – 4-digit installer code; at – number of attempts, range – [1... 10].
EKB3/
EKB3W/
EWKB4
Enter parameter 84 and number of attempts:
84 at #
Value: at – number of attempts, range – [01... 10].
Example: 8403#
ELDES
Cong-
uration
software
This operation may be carried out from the PC using the ELDES Conguration software.
