112
Section G - Ice and Water Dispenser
G 10
599485595 August 2007
Replace cube/
crush solenoid
and retest
Yes
Replace UI and
retest
No
No
No
Are outputs
correct on the
harness at cube/
crush solenoid
connector?
(120V)
Is 120V present
at main board J3-
pin 3 (blue/white
wire) connector
when paddle
depressed and
ice selected?
Replace ERF
2500++;
Is problem fixed?
Yes
Repair/replace
solenoid
harness and
retest
Is 120V present
at freezer liner
connection pin 3?
Repair/replace
harness and
retest
Yes
No
No
Yes
Is freezer -
machine
compartment
inline connected?
No
Connect and
retest
