Section G - Ice and Water Dispenser
G 11
599485595 August 2007
Replace switch
and retest
No
Replace
ERF2500++ and
retest.
No
Yes
Yes
Does light switch
have continuity
when opened and
no continuity
when closed?
Is 120V present
on yellow/pink
wire?
No
Repair/replace
machine
compartment
harness and
retest
Is yellow/pink
wire continuity
intact from inline
to switch?
Repair/replace
freezer harness
and retest
Yes
No
No
Yes
Is freezer-
machine
compartment
inline connection
intact?
No
Connect and
retest
Is yellow/red wire
continuity intact
from inline to
switch?
Repair/replace
freezer harness
and retest
No
No
Yes
Is freezer-
machine
compartment
inline connection
intact?
No
Connect and
retest
Is yellow/red wire
continuity intact
from inline to MB
J1-pin 7?
Repair/replace
freezer harness
and retest
No
Yes
Yes
Replace bulbs
and retest
No
Yes
Are all light bulbs
burned out?
Section 5
G 10
599485595 August 2007
Replace cube/
crush solenoid
and retest
Yes
Replace UI and
retest
No
No
No
Are outputs
correct on the
harness at cube/
crush solenoid
connector?
(120V)
Is 120V present
at main board J3-
pin 3 (blue/white
wire) connector
when paddle
depressed and
ice selected?
Replace ERF
2500++;
Is problem fixed?
Yes
Repair/replace
solenoid
harness and
retest
Is 120V present
at freezer liner
connection pin 3?
Repair/replace
harness and
retest
Yes
No
No
Yes
Is freezer -
machine
compartment
inline connected?
No
Connect and
retest
Section 4
Section 5
