Section G - Ice and Water Dispenser
G 12
599485595 August 2007
Repair/replace
connection and
retest.
Repair/replace
harness and
retest
Yes
Replace UI and
retest
No
No
Are paddle
microswitch
connections at
switch intact?
Is 6 wire
connection to UI
driver board
intact?
Yes
Is microswitch
properly
mounted?
Yes
Is microswitch
electrically closed
when pressed
and electrically
open when not
pressed?
Yes
Repair/replace
microswitch
No
Repair/replace
microswitch
No
Is microswitch
actuated by
paddle
mechanism
during normal
user operation?
Yes
Repair/replace
microswitch
No
Section 6
Flapper
Section 6
