ELITE OPERATOR’S MANUAL
260
Cockpit Functions
Dummy
Generator
Warning
Fuel
Selector
Parking
Brake
Test
Switch
Pitot Heat
Fuel
Pump
Taxi
Light
Landing Light
Autopilot
Engaged
Light
Dim SwitchLow Oil
Pressure
Warning
Dummy light: Not used.
Generator Warning light: Illuminates when the voltage is
low or the engine is operated below 1000 RPM.
Fuel Selector light: Illuminates when the fuel tank selector
is in the ‘off’ position.
Parking Brake light: Illuminates when the parking brake is
set.
Low Oil Pressure Warning light: Illuminates when oil
pressure is low or the engine is not running.
Test Switch: Click on this switch to test all annunciator
lights.
Dim Switch: Dims all lights for use at night.
Fuel Pump light: Illuminates when the electric fuel pump
is activated.
Pitot Heat light: Illuminates when the pitot heat is
activated.
Taxi / Landing Light: Illuminates when the Taxi or Landing
light switches are activated.
Autopilot Engaged light: Illuminates when the autopilot is
engaged.
