Localizer (yellow) transmitter
Glideslope (red) transmitter
Runway with displaced threshold
Airport Symbol
Communication frequencies
MAP CURSORS
The cursor changes for different functions on the MAP
page:
Normal cursor (fi ngertip)
Zoom in cursor (Alt Key)
Zoom out cursor (Shift-Alt)
Zoom limit (either enlarging or reducing)
Heading/Distance (Shift key)
Add point (Route planner) (Control key)
Remove point (Route planner) (Control-Alt)
Change/Move Point (Route planner)
(Shift-Control keys)
Active Runway
Click on the box for other shortcuts.
