Configureprocessmeasurement
Table5-4OptionsforFlowDirection
FlowDirectionsetting
ProLinkIIFieldCommunicator
ForwardForward
ReverseReverse
AbsoluteValueAbsoluteValue
BidirectionalBidirectional
NegateForward
Negate/ForwardOnly
NegateBidirectional
Negate/Bi-directional
5.5.2EffectofFlowDirectionontransmitteroutputsandtotalizers
FlowDirectionandmAoutputs
mAoutputsareaffectedbyFlowDirectiononlyifmAOutputProcessVariableissettoaowvariable.
TheeffectofFlowDirectiononmAoutputsdependontheLowerRangeValueconguredforthemAoutput:
•IfLowerRangeValueissetto0,seeFigure5-5.
•IfLowerRangeValueissettoanegativevalue,seeFigure5-6.
Figure5-5EffectofFlowDirectiononthemAoutput:LowerRangeValue=0
Notes
•LowerRangeValue=0
•UpperRangeValue=x
80MicroMotion9739MVDTransmitters
