142
Reference Manual
00809-0100-2460, Rev DE
Service and Troubleshooting
October 2018
Service and Troubleshooting
6.22 Fuses
Two T1.6A fuses are located on the Power Board inside the Rosemount
™
2460 housing. See
Figure 6-8.
Figure 6-8. Two T1.6A 250V fuses inside the Rosemount 2460 housing
Fuses: 2xT1.6A 250 V
Power Board
