F.4.2 System register area
Table F-5. System Register Area
Register
Number
Register Name Type Unit Description
2460 Status Register Area Priority 5 question. Defines the unit for
the values in the FC04 area.
24000 Device Status DWORD Bitfield Priority 1 question
Bit 0: Simulation Mode Active
Bit 1: Device Warning
Bit 2: Device Error
Bit 3: SW Write Protection Active
Bit 4: HW Write Protection Active
Bit 10: Redundant System
Bit 11: Redundant Primary Device
Bit 12: Redundant Active Device
24002 Device Error DWORD Bitfield Bit 0: Firmware Error
Bit 1: CDB Error
Bit 7: IPC Error
Bit 14: SW Error
Bit 17: Internal System Error
Bit 18: License Error
24004 Device Warning DWORD Bitfield Bit 0: Firmware Warning
Bit 1: CDB Warning
Bit 4: Redundancy Warning
Bit 5: Modem Warning
Bit 14: Battery Warning
Bit 15: USB Warning
Bit 16: SD-Card Warning
Bit 17: Internal System Warning
Bit 18: License Conflict
24006 Device Operation Mode WORD Enum 0 = Full Mode
1 = Warning Mode
2 = Error Mode
