Reference Manual

00809-0100-2460, Rev DE

Overview

October 2018

Overview

Section 2 Overview

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7

Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 8

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 9

System overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 13

Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 20

2.1 Introduction

In a typical Rosemount

™

Tank Gauging system, a Rosemount 2460 System Hub collects measurement

data and status information from various field devices. A standard installation includes a

Rosemount 2460 connected to a number of Rosemount 2410 Tank Hubs which collect measurement

data and status information from the field devices.

A Rosemount 2460 buffers measurement data and status information from one or more tanks, and

sends the information to a TankMaster PC, or other host system, whenever the

Rosemount 2460 receives a

request for data.

Figure 2-1. System integration
