Emerson Rosemount 2460 System Hub User Manual

159Specifications and Reference Data
Specifications and Reference Data
October 2018
Reference Manual
00809-0100-2460, Rev DE
Figure A-1. Typical Configuration of a Rosemount 2460 System Hub
Figure A-2. Typical Redundant Configuration
Modem
USB
RS232
Rosemount 2460 System Hub
TRL2,
RS485
Rosemount 2410 Tank Hub
Ta nk b us
Secondary bus: Enraf, Whessoe and others,
HART 4-20 mA analog output/input
DCS/Host
(TRL2, RS485, RS232)
Primary bus:
TRL2, RS485
Field devices
RS232
TRL2,
RS485
other vendors
Ta nk Master
Modbus RTU/TCP
Host
Field devices
Ta nk bus
Field devices
Rosemount
2410 Tank Hub
Rosemount 2460 System Hub,
primary
Rosemount 2460 System Hub,
secondary
Redundancy control signal
Ta nk Master
Modem
