162 Specifications and Reference Data
Specifications and Reference Data
October 2018
Reference Manual
00809-0100-2460, Rev DE
Figure A-4. Top view
374 (14.7)
12.5 (4.9) x4
87 (3.4)
36 (1.4)
6.5 (0.3) x4
474 (18.7) with lid maximum open
465
(18.3)
Dimensions are in mm (inch).
