ProlineйPromagйHй100йEtherNet/IP Productйdescription
Endress+Hauser 11
3 Product description
3.1 Product design
3.1.1 Device version with EtherNet/IP communication type
3
2
1
4
5
6
7
ййA0023153
 1 Important components of a measuring device
1 Sensor
2 Transmitter housing
3 Main electronics module
4 Transmitter housing cover
5 Transmitter housing cover (version for optional onsite display)
6 Onsite display (optional)
7 Main electronics module (with bracket for optional onsite display)
