Systemйintegration ProlineйPromagйHй100йEtherNet/IP
46 Endress+Hauser
9 System integration
9.1 Overview of device description files
9.1.1 Current version data for the device
Firmwareйversion 01.01.zz • OnйtheйtitleйpageйofйtheйOperatingйinstructions
• Onйtransmitterйnameplateсййй12)
• Parameterйfirmware version
DiagnosticsййDeviceйinfoйFirmwareйversion
Releaseйdateйofйfirmwareйversion 10.2014 ---
ManufacturerйID 0x49E Manufacturer IDйparameter
DiagnosticsййDeviceйinfoйManufacturerйID
DeviceйtypeйID 0x103A Device typeйparameter
DiagnosticsййDeviceйinfoййDeviceйtype
Deviceйrevision • Majorйrevision
2
• Minor
revisionй1
• Onйtransmitterйnameplateсййй12)
• Device revisionйparameter
DiagnosticsййDeviceйinfoййDeviceйrevision
Deviceйprofile Genericйdeviceйсproductйtype:й0x2B)
9.1.2 Operating tools
Theйsuitableйdeviceйdescriptionйfileйforйtheйoperatingйtoolйisйlistedйinйtheйtableйbelow,йalong
withйinformationйonйwhereйtheйfileйcanйbeйacquired.
Operating tool via service
interface (CDI)
Sources for obtaining device descriptions
FieldCare • www.endress.comййDownloadйArea
• CD–ROMйсcontactйEndress+Hauser)
• DVDйсcontactйEndress+Hauser)
9.2 Overview of system files
System files Version Description How to acquire
ElectronicйData
SheetйсEDS
systemйfile)
2.1 Certifiedйinйaccordanceйwithйthe
followingйODVAйguidelines:
• Conformanceйtest
• Performanceйtest
• PlugFest
EmbeddedйEDSйSupportйсFileйObject
0x37)
• www.endress.comййDownload
Area
• EDSйsystemйfileйintegratedйinйthe
device:йcanйbeйdownloadedйvia
theйWebйbrowserйсййй41)
Add-onйProfile
Levelй3
• Majorйrevision
2
• Minor
revisionй1
Systemйfileйforй"RSLogixй5000"
softwareйсRockwellйAutomation)
www.endress.comййDownload
Area
9.3 Integrating the measuring device in the system
Aйdetailedйdescriptionйofйhowйtoйintegrateйtheйdeviceйintoйanйautomationйsystemйсe.g.
fromйRockwellйAutomation)йisйavailableйasйaйseparateйdocument:й
www.endress.comй
SelectйcountryййAutomationйййDigitalйCommunicationййFeldbusйdevice
integrationййEtherNet/IP
