ProlineйPromagйHй100йEtherNet/IP Diagnosticsйandйtroubleshooting
Endress+Hauser 69
12.3 Diagnostic information in the Web browser
12.3.1 Diagnostic options
AnyйfaultsйdetectedйbyйtheйmeasuringйdeviceйareйdisplayedйinйtheйWebйbrowserйonйthe
homeйpageйonceйtheйuserйhasйloggedйon.
1
3
2
ййA0017759-EN
1
2
3
Status area with status signal
Diagnostic information
Remedial measures with Service ID
Furthermore,йdiagnosticйeventsйthatйhaveйoccurredйcanйbeйviewedйinйtheйDiagnostics
menu:
Viaйparametersйсййй74)
Viaйsubmenusйсййй75)
Status signals
Theйstatusйsignalsйprovideйinformationйonйtheйstateйandйreliabilityйofйtheйdeviceйby
categorizingйtheйcauseйofйtheйdiagnosticйinformationйсdiagnosticйevent).
Symbol Meaning
ййA0017271
Failure
Aйdeviceйerrorйhasйoccurred.йTheйmeasuredйvalueйisйnoйlongerйvalid.
ййA0017278
Function check
Theйdeviceйisйinйserviceйmodeйсe.g.йduringйaйsimulation).
ййA0017277
Out of specification
Theйdeviceйisйoperated:
Outsideйitsйtechnicalйspecificationйlimitsйсe.g.йoutsideйtheйprocessйtemperatureйrange)
ййA0017276
Maintenance required
Maintenanceйisйrequired.йTheйmeasuredйvalueйisйstillйvalid.
TheйstatusйsignalsйareйcategorizedйinйaccordanceйwithйVDI/VDEй2650йandйNAMUR
RecommendationйNEй107.
