Commissioning ProlineйPromagйHй100йEtherNet/IP
52 Endress+Hauser
Parameter Description Selection / User entry Factory setting
Valueй2йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
Picklistйсseeй1stйdisplayйvalue) None
Valueй3йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
Picklistйсseeй1stйdisplayйvalue) None
0%йbargraphйvalueй3 Enterй0%йvalueйforйbarйgraphйdisplay. Signedйfloating-pointйnumber 0
100%йbargraphйvalueй3 Enterй100%йvalueйforйbarйgraphйdisplay. Signedйfloating-pointйnumber 0
Valueй4йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
Picklistйсseeй1stйdisplayйvalue) None
10.3.4 Configuring the communication interface
Theй"Communication" submenuйguidesйyouйsystematicallyйthroughйallйtheйparameters
thatйhaveйtoйbeйconfiguredйforйselectingйandйsettingйtheйcommunicationйinterface.
Navigation
"Setup"йmenuййCommunication
Structure of the submenu
Communication
MACйaddress
Defaultйnetworkйsettings
DHCPйclient
IPйaddress
Subnetйmask
Defaultйgateway
Parameter overview with brief description
Parameter Description User interface / Selection /
User entry
Factory setting
MACйaddress DisplaysйtheйMACйaddressйofйtheйmeasuring
device.
MACй=йMediaйAccessйControl
Uniqueй12-digitйcharacter
stringйcomprisingйlettersйand
numbers,йe.g.:
00:07:05:10:01:5F
Eachйmeasuringйdeviceйisйgiven
anйindividualйaddress.
Defaultйnetworkйsettings Selectйwhetherйtoйrestoreйnetworkйsettings. • Off
• On
Off
DHCPйclient Selectйtoйactivate/deactivateйDHCPйclient
functionality.
Result
IfйtheйwebйserverрsйDHCPйclientйfunctionality
isйactivated,йtheйIPйaddress,йsubnetйmaskйand
defaultйgatewayйareйautomaticallyйset.
IdentificationйisйviaйtheйMACйaddress
ofйtheйmeasuringйdevice.
• Off
• On
On
IPйaddress DisplaysйtheйIPйaddressйofйtheйWebйserverйof
theйmeasuringйdevice.
4йoctet:й0йtoй255йсinйthe
particularйoctet)
192.168.1.212
