ProlineйPromagйHй100йEtherNet/IP Mounting
Endress+Hauser 19
Horizontal
ййA0019602
1 EPD electrode for empty pipe detection
2 Measuring electrodes for signal detection
• Theйmeasuringйelectrodeйplaneйmustйbeйhorizontal.йThisйpreventsйbriefйinsulationйof
theйtwoйmeasuringйelectrodesйbyйentrainedйairйbubbles.
• Theйemptyйpipeйdetectionйonlyйworksйifйtheйtransmitterйhousingйisйpointingйupwards
asйotherwiseйthereйisйnoйguaranteeйthatйtheйemptyйpipeйdetectionйfunctionйwill
actuallyйrespondйtoйaйpartiallyйfilledйorйemptyйmeasuringйtube.
Inlet and outlet runs
Ifйpossible,йinstallйtheйsensorйupstreamйfromйfittingsйsuchйasйvalves,йT-piecesйorйelbows.
Observeйtheйfollowingйinletйandйoutletйrunsйtoйcomplyйwithйaccuracyйspecifications:
ййA0016275
Installation dimensions
Forйtheйdimensionsйandйinstallationйlengthsйofйtheйdevice,йseeйtheй"Technical
Information"йdocument,й"Mechanicalйconstruction"йsection
6.1.2 Requirements from environment and process
Ambient temperature range
Transmitter –40йtoй+60й°Cйс–40йtoй+140й°F)
Sensor –20йtoй+60й°Cйс–4йtoй+140й°F)
Liner Doйnotйexceedйorйfallйbelowйtheйpermittedйtemperatureйrangeйofйtheйliner
сййй93).
Ifйoperatingйoutdoors:
• Installйtheйmeasuringйdeviceйinйaйshadyйlocation.
• Avoidйdirectйsunlight,йparticularlyйinйwarmйclimaticйregions.
• Avoidйdirectйexposureйtoйweatherйconditions.
