ProlineйPromagйHй100йEtherNet/IP Operation
Endress+Hauser 63
11 Operation
11.1 Read out and modify current Ethernet settings
IfйtheйEthernetйsettingsйsuchйasйtheйIPйaddressйofйtheйmeasuringйdeviceйareйunknown,йthey
canйbeйreadйoutйandйmodifiedйasйexplainedйinйtheйfollowingйexampleйforйanйIPйaddress.
OFF ON
1
2
3
4
5
6
7
8
9
10
1
2
4
8
16
32
64
128
- Write protection
- Default Ethernet
network settings
IP 192.168.1.212
IP Address setting
(last octet)
ййA0017965
Prerequisite
• Softwareйaddressingйisйenabled:йAllйtheйDIPйswitchesйforйhardwareйaddressingйareйsetйto
OFF.йсййй33)
• Measuringйdeviceйisйswitchedйon.
1. SetйtheйDIPйswitchйforй"DefaultйEthernetйnetworkйsettings,йIPй192.168.1.212"йfrom
OFFййON.
2. Restartйtheйdevice.
 TheйdeviceрsйEthernetйsettingsйareйresetйtoйtheirйfactoryйsettings:
IPйaddress:й192.168.1.212;йSubnetйmask:й255.255.255.0;йDefaultйgateway:
192.168.1.212
3. EnterйtheйdefaultйsettingйforйtheйIPйaddressйinйtheйaddressйlineйofйtheйWebйbrowser.
4. InйtheйoperatingйmenuйnavigateйtoйtheйIP addressйparameter:й"Setup"йmenuй
CommunicationййIPйaddress
 TheйparameterйdisplaysйtheйconfiguredйIPйaddress.
5. ChangeйtheйIPйaddressйofйtheйdeviceйifйnecessary.
6. SetйtheйDIPйswitchйforй"DefaultйEthernetйnetworkйsettings,йIPй192.168.1.212"йfromйON
йOFF.
7. Restartйtheйdevice.
 TheйmodifiedйIPйaddressйofйtheйdeviceйisйnowйenabled.
11.2 Reading device locking status
TheйwriteйprotectionйtypesйthatйareйcurrentlyйactiveйcanйbeйdeterminedйusingйtheйLocking
statusйparameter.
