Endress+Hauser Proline Promag H 100 EtherNet/IP User Manual

ProlineйPromagйHй100йEtherNet/IP Technicalйdata
Endress+Hauser 87
Fieldbus
Theйmeasuredйvaluesйareйwrittenйfromйtheйautomationйsystemйtoйtheйmeasuringйdeviceйvia
EtherNet/IP.
16.4 Output
Outputйsignal EtherNet/IP
Standards InйaccordanceйwithйIEEEй802.3
Signalйonйalarm Dependingйonйtheйinterface,йfailureйinformationйisйdisplayedйasйfollows:
EtherNet/IP
Device diagnostics DeviceйconditionйcanйbeйreadйoutйinйInputйAssembly
Local display
Plain text display Withйinformationйonйcauseйandйremedialйmeasures
Backlight Redйbacklightingйindicatesйaйdeviceйerror.
StatusйsignalйasйperйNAMURйrecommendationйNEй107
Operating tool
• Viaйdigitalйcommunication:
EtherNet/IP
• Viaйserviceйinterface
Plain text display Withйinformationйonйcauseйandйremedialйmeasures
Web browser
Plain text display Withйinformationйonйcauseйandйremedialйmeasures
Light emitting diodes (LED)
Status information Statusйindicatedйbyйvariousйlightйemittingйdiodes
Theйfollowingйinformationйisйdisplayedйdependingйonйtheйdeviceйversion:
• Supplyйvoltageйactive
• Dataйtransmissionйactive
• Deviceйalarm/errorйhasйoccurred
• EtherNet/IPйnetworkйavailable
• EtherNet/IPйconnectionйestablished
Lowйflowйcutйoff Theйswitchйpointsйforйlowйflowйcutйoffйareйuser-selectable.

Endress+Hauser Proline Promag H 100 EtherNet/IP Specifications

General

Brand	Endress+Hauser
Model	Proline Promag H 100 EtherNet/IP
Category	Measuring Instruments
Language	English
