ProlineйPromagйHй100йEtherNet/IP Technicalйdata
Endress+Hauser 97
Spacer
1.4435йсF316L)
Fittedйelectrodes • 2йmeasuringйelectrodesйforйsignalйdetection
• 1йemptyйpipeйdetectionйelectrodeйforйemptyйpipeйdetection/temperatureйmeasurement
сonlyйDNй15йtoй150йс½йtoй6"))
Processйconnections WithйO-ringйseal
• WeldedйconnectionйсDINйENйISOй1127,йODT/SMS,йISOй2037)
• FlangeйсENйсDIN),йASME,йJIS)
• FlangeйfromйPVDFйсENйсDIN),йASME,йJIS)
• Externalйthread
• Internalйthread
• Hoseйconnection
• PVCйadhesiveйsleeve
Withйasepticйmoldedйseal:
• WeldedйconnectionйсDINй11850,йASMEйBPE,йISOй2037)
• ClampйсISOй2852,йISOй2853,йDINй32676,йL14йAM7)
• CouplingйсDINй11851,йDINй11864-1,йISOй2853,йSMSй1145)
• FlangeйDINй11864-2
Forйinformationйonйtheйmaterialsйofйtheйprocessйconnectionsйсййй96)
Surfaceйroughness Stainlessйsteelйelectrodes,й1.4435йсF316L);йAlloyйC22,й2.4602йсUNSйN06022);йplatinum;
tantalum:
≤й0.3йtoй0.5йµmйс11.8йtoй19.7йµin)
сAllйdataйrelateйtoйpartsйinйcontactйwithйfluid)
LinerйwithйPFA:
≤й0.4йµmйс15.7йµin)
сAllйdataйrelateйtoйpartsйinйcontactйwithйfluid)
Stainlessйsteelйprocessйconnections:
≤й0.8йµmйс31йµin)
Optional:й≤й0.38йµmйс15йµin)
сAllйdataйrelateйtoйpartsйinйcontactйwithйfluid)
16.11 Operability
Localйdisplay Theйlocalйdisplayйisйonlyйavailableйwithйtheйfollowingйdeviceйversion:
Orderйcodeйforй"Display;йOperation",йoptionйB:й4-line;йviaйcommunication
Display element
• 4-lineйliquidйcrystalйdisplayйwithй16йcharactersйperйline.
• Whiteйbackgroundйlighting;йswitchesйtoйredйinйeventйofйdeviceйerrors.
• Formatйforйdisplayingйmeasuredйvariablesйandйstatusйvariablesйcanйbeйindividually
configured.
• Permittedйambientйtemperatureйforйtheйdisplay:й–20йtoй+60й°Cйс–4йtoй+140й°F).йThe
readabilityйofйtheйdisplayйmayйbeйimpairedйatйtemperaturesйoutsideйtheйtemperature
range.
