Electricalйconnection ProlineйPromagйHй100йEtherNet/IP
34 Endress+Hauser
Setting the address
OFF ON
1
2
3
4
5
6
7
8
9
10
1
2
4
8
16
32
64
128
- Write protection
- Default Ethernet
network settings
IP 192.168.1.212
IP Address setting
(last octet)
ййA0017913
1. Dependingйonйtheйhousingйversion,йloosenйtheйsecuringйclampйorйfixingйscrewйofйthe
housingйcover.
2. Dependingйonйtheйhousingйversion,йunscrewйorйopenйtheйhousingйcoverйand
disconnectйtheйlocalйdisplayйfromйtheйmainйelectronicsйmoduleйwhereйnecessary
сййй98).
3. SetйtheйdesiredйIPйaddressйusingйtheйcorrespondingйDIPйswitchesйonйtheйI/O
electronicsйmodule.
HardwareйaddressingйwithйtheйconfiguredйIPйaddressйisйenabledйafterй10йs.
4. Reverseйtheйremovalйprocedureйtoйreassembleйtheйtransmitter.
7.5 Ensuring the degree of protection
TheйmeasuringйdeviceйfulfillsйallйtheйrequirementsйforйtheйIP66/67йdegreeйofйprotection,
Typeй4Xйenclosure.
ToйguaranteeйIP66/67йdegreeйofйprotection,йTypeй4Xйenclosure,йcarryйoutйtheйfollowing
stepsйafterйtheйelectricalйconnection:
1. Checkйthatйtheйhousingйsealsйareйcleanйandйfittedйcorrectly.йDry,йcleanйorйreplaceйthe
sealsйifйnecessary.
2. Tightenйallйhousingйscrewsйandйscrewйcovers.
3. Firmlyйtightenйtheйcableйglands.
4. Toйensureйthatйmoistureйdoesйnotйenterйtheйcableйentry,йrouteйtheйcableйsoйthatйit
loopsйdownйbeforeйtheйcableйentryйс"waterйtrap").
ййA0013960
5. Insertйdummyйplugsйintoйunusedйcableйentries.
