Commissioning ProlineйPromagйHй100йEtherNet/IP
48 Endress+Hauser
10 Commissioning
10.1 Function check
Beforeйcommissioningйtheйdevice,йmakeйsureйthatйtheйpost-installationйandйpost-
connectionйchecksйhaveйbeenйperformed.
• "Post-installationйcheck"йchecklistйсййй25)
• "Post-connectionйcheck"йchecklistйсййй35)
10.2 Configuring the device address via software
Inйtheй"Communication" submenuйtheйdeviceйaddressйcanйbeйset.
Navigation
"Setup"йmenuййCommunicationййDeviceйaddress
10.2.1 Ethernet network and Web server
Whenйdelivered,йtheйmeasuringйdeviceйhasйtheйfollowingйfactoryйsettings:
IP address 192.168.1.212
Subnet mask 255.255.255.0
Default gateway 192.168.1.212
• Ifйhardwareйaddressingйisйactive,йsoftwareйaddressingйisйdisabled.
• Ifйaйswitchйisйmadeйtoйhardwareйaddressing,йtheйaddressйconfiguredйviaйsoftware
addressingйisйretainedйforйtheйfirstй9йplacesйсtheйfirstйthreeйoctets).
• IfйtheйIPйaddressйofйtheйdeviceйisйnotйknown,йtheйdeviceйaddressйcurrentlyйconfigured
canйbeйreadйoutйсййй63).
10.3 Configuring the measuring device
TheйSetupйmenuйwithйitsйsubmenusйcontainsйallйtheйparametersйneededйforйstandard
operation.
Structure of the "Setup" menu
Setup

Deviceйtag
сййй48)
System units
сййй49)
Communication
сййй52)
Display
сййй50)
Low flow cut off
сййй53)
Empty pipe detection
сййй54)
10.3.1 Defining the tag name
Toйenableйfastйidentificationйofйtheйmeasuringйpointйwithinйtheйsystem,йyouйcanйenterйa
uniqueйdesignationйusingйtheйDevice tagйparameterйandйthusйchangeйtheйfactoryйsetting.
