Terminals Transmitter
Springйterminalsйforйwireйcross-sections0.5йtoй2.5йmm
2
йс20йtoй14йAWG)
Cableйentries • Cableйgland:йM20й×й1.5йwithйcableй6йtoй12йmmйс0.24йtoй0.47йin)
• Threadйforйcableйentry:
– NPTй½"
– Gй½"
– M20
Cableйspecification сййй27)
16.6 Performance characteristics
Referenceйoperating
conditions
In accordance with DIN EN 29104
• Fluidйtemperature:й+28±2й°Cйс+82±4й°F)
• Ambientйtemperatureйrange:й+22±2й°Cйс+72±4й°F)
• Warm-upйperiod:30йmin
Installation
• Inletйrunй>й10й×йDN
• Outletйrunй>й5й×йDN
• Sensorйandйtransmitterйgrounded.
• Theйsensorйisйcenteredйinйtheйpipe.
Maximumйmeasuredйerror Error limits under reference operating conditions
o.r.й=йofйreading
Volume flow
• ±0.5й%йo.r.й±й1йmm/sйс0.04йin/s)
• Optional:й±0.2й%йo.r.й±й2йmm/sйс0.08йin/s)
Fluctuationsйinйtheйsupplyйvoltageйdoйnotйhaveйanyйeffectйwithinйtheйspecifiedйrange.
2.5
[%]
2.0
1.5
1.0
0.5
0
0.2 %
0.5 %
0
1
2 4 6 8 10 [m/s]
v
5 10 15 20 25 30 32 [ft/s]0
ййA0005531
 15 Maximum measured error in % o.r.
Temperature
±3й°Cйс±5.4й°F)
Electrical conductivity
Max.йmeasuredйerrorйnotйspecified.
