ProlineйPromagйHй100йEtherNet/IP Electricalйconnection
Endress+Hauser 31
2. Dependingйonйtheйhousingйversion,йunscrewйorйopenйtheйhousingйcoverйand
disconnectйtheйlocalйdisplayйfromйtheйmainйelectronicsйmoduleйwhereйnecessary
сййй98).
3. Pushйtheйcableйthroughйtheйcableйentryй.йToйensureйtightйsealing,йdoйnotйremoveйthe
sealingйringйfromйtheйcableйentry.
4. Stripйtheйcableйandйcableйends.йInйtheйcaseйofйstrandedйcables,йalsoйfitйferrules.
5. Connectйtheйcableйinйaccordanceйwithйtheйterminalйassignmentйorйtheйdeviceйplugйpin
assignmentй.
6. Dependingйonйtheйdeviceйversion:йtightenйtheйcableйglandsйorйplugйinйtheйdeviceйplug
andйtightenй.
7. WARNING! Housingйdegreeйofйprotectionйmayйbeйvoidedйdueйtoйinsufficientйsealingйof
theйhousing.йScrewйinйtheйscrewйwithoutйusingйanyйlubricant.йTheйthreadsйonйthe
coverйareйcoatedйwithйaйdryйlubricant.
Reverseйtheйremovalйprocedureйtoйreassembleйtheйtransmitter.
7.2.2 Ensuring potential equalization
CAUTION
Electrode damage can result in the complete failure of the device!
Makeйsureйthatйtheйfluidйandйsensorйhaveйtheйsameйelectricalйpotential.
Payйattentionйtoйinternalйgroundingйconceptsйinйtheйcompany.
Payйattentionйtoйtheйpipeйmaterialйorйgrounding.
Connection examples for standard situations
Metal process connections
Potentialйmatchingйusuallyйtakesйplaceйviaйtheйmetallicйprocessйconnectionsйinйcontactйwith
mediumйwhichйareйdirectlyйmountedйonйtheйmeasuringйtransmitter.йThisйusuallyйmeans
thatйadditionalйpotentialйmatchingйmeasuresйareйunnecessary.
Connection example in special situations
Plastic process connections
Inйtheйcaseйofйplasticйprocessйconnections,йadditionalйgroundingйringsйorйprocess
connectionsйwithйanйintegratedйgroundingйelectrodeйmustйbeйusedйtoйensureйpotential
matchingйbetweenйtheйsensorйandйtheйfluid.йIfйthereйisйnoйpotentialйmatching,йthisйcan
affectйtheйmeasuringйaccuracyйorйcauseйtheйdestructionйofйtheйsensorйasйaйresultйofйthe
electrochemicalйdecompositionйofйtheйelectrodes.
Noteйtheйfollowingйwhenйusingйgroundingйrings:
Dependingйonйtheйoptionйordered,йplasticйdisksйareйusedйinsteadйofйgroundingйringsйon
someйprocessйconnections.йTheseйplasticйdisksйonlyйactйasй"spacers"йandйdoйnotйhaveйany
potentialйmatchingйfunction.йFurthermore,йtheyйalsoйperformйaйsignificantйsealing
functionйatйtheйsensor/connectionйinterface.йTherefore,йinйtheйcaseйofйprocess
connectionsйwithoutйmetalйgroundingйrings,йtheseйplasticйdisks/sealsйshouldйneverйbe
removedйandйshouldйalwaysйbeйinstalledк
GroundingйringsйcanйbeйorderedйseparatelyйasйanйaccessoryйfromйEndress+Hauserй.йWhen
orderingйmakeйsureйthatйtheйgroundingйringsйareйcompatibleйwithйtheйmaterialйusedйfor
theйelectrodes,йasйotherwiseйthereйisйtheйdangerйthatйtheйelectrodesйcouldйbeйdestroyedйby
electrochemicalйcorrosionк
Groundingйrings,йincludingйseals,йareйmountedйinsideйtheйprocessйconnections.йTherefore
theйinstallationйlengthйisйnotйaffected.
