Technicalйdata ProlineйPromagйHй100йEtherNet/IP
98 Endress+Hauser
Disconnecting the local display from the main electronics module
Inйtheйcaseйofйtheй"Compact,йaluminumйcoated"йhousingйversion,йtheйlocalйdisplayйmust
onlyйbeйdisconnectedйmanuallyйfromйtheйmainйelectronicsйmodule.йInйtheйcaseйofйthe
"Compact,йhygienic,йstainless"йandй"Ultraйcompact,йhygienic,йstainless"йhousingйversions,
theйlocalйdisplayйisйintegratedйinйtheйhousingйcoverйandйisйdisconnectedйfromйtheйmain
electronicsйmoduleйwhenйtheйhousingйcoverйisйopened.
"Compact, aluminum coated" housing version
Theйlocalйdisplayйisйpluggedйontoйtheйmainйelectronicsйmodule.йTheйelectronicйconnection
betweenйtheйlocalйdisplayйandйmainйelectronicsйmoduleйisйestablishedйviaйaйconnecting
cable.
Forйsomeйworkйperformedйonйtheйmeasuringйdeviceйсe.g.йelectricalйconnection),йitйis
advisableйtoйdisconnectйtheйlocalйdisplayйfromйtheйmainйelectronicsйmodule:
1. Pressйinйtheйsideйlatchesйofйtheйlocalйdisplay.
2. Removeйtheйlocalйdisplayйfromйtheйmainйelectronicsйmodule.йPayйattentionйtoйthe
lengthйofйtheйconnectingйcableйwhenйdoingйso.
Onceйtheйworkйisйcompleted,йplugйtheйlocalйdisplayйbackйon.
Remoteйoperation Via Ethernet-based fieldbus
ййA0016961
1 Ethernet network
2 Automation system, e.g. "RSLogix" (Rockwell Automation)
3 Workstation for measuring device operation: with Add-on Profile Level 3 for "RSLogix 5000" (Rockwell
Automation) or with Electronic Data Sheet (EDS)
4 Computer with Web browser (e.g. Internet Explorer) for accessing the integrated device Web server or with
"FieldCare" operating tool with COM DTM "CDI Communication TCP/IP"
5 Ethernet switch
Serviceйinterface Service interface (CDI-RJ45)
