Mounting ProlineйPromagйHй100йEtherNet/IP
22 Endress+Hauser
6.2.3 Mounting the sensor
WARNING
Danger due to improper process sealing!
Ensureйthatйtheйinsideйdiametersйofйtheйgasketsйareйgreaterйthanйorйequalйtoйthatйofйthe
processйconnectionsйandйpiping.
Ensureйthatйtheйgasketsйareйcleanйandйundamaged.
Installйtheйgasketsйcorrectly.
1. Ensureйthatйtheйdirectionйofйtheйarrowйonйtheйsensorйmatchesйtheйflowйdirectionйof
theйmedium.
2. Toйensureйcomplianceйwithйdeviceйspecifications,йinstallйtheйmeasuringйdevice
betweenйtheйpipeйflangesйinйaйwayйthatйitйisйcenteredйinйtheйmeasurementйsection.
3. Installйtheйmeasuringйdeviceйorйturnйtheйtransmitterйhousingйsoйthatйtheйcableйentries
doйnotйpointйupwards.
ййA0013964
Theйsensorйisйsuppliedйtoйorder,йwithйorйwithoutйpre-installedйprocessйconnections.йPre-
installedйprocessйconnectionsйareйfirmlyйsecuredйtoйtheйsensorйbyй4йorй6йhexagonal-headed
bolts.
Theйsensorйmayйneedйtoйbeйsupportedйorйadditionallyйsecuredйdependingйonйthe
applicationйandйpipeйlength.йInйparticular,йitйisйabsolutelyйessentialйtoйsecureйtheйsensor
additionallyйifйplasticйprocessйconnectionsйareйused.йAnйappropriateйwallйmountingйkit
canйbeйorderedйseparatelyйasйanйaccessoryйfromйEndress+Hauserйсййй101).
A
B
C
DN 2…25
(1/12…1 )"
DN 40…150
( …6 )1 ½ "
ййA0019804
 6 Process connection seals
A Process connections with O-ring seal(→  97)
B Process connections with aseptic molded seal, DN 2 to 25 (1/12 to 1")(→  97)
C Process connections with aseptic molded seal, DN 40 to 150 (1 ½ to 6")(→  97)
Welding the sensor into the pipe (welding connections)
WARNING
Risk of destroying the electronics!
Makeйsureйthatйtheйweldingйsystemйisйnotйgroundedйviaйtheйsensorйorйtransmitter.
