ProlineйPromagйHй100йEtherNet/IP Mounting
Endress+Hauser 23
1. Tack-weldйtheйsensorйtoйsecureйitйinйtheйpipe.йAйsuitableйweldingйaidйcanйbeйordered
separatelyйasйanйaccessoryйсййй101).
2. Releaseйtheйscrewsйonйtheйprocessйconnectionйflangeйandйremoveйtheйsensor,йalong
withйtheйseal,йfromйtheйpipe.
3. Weldйtheйprocessйconnectionйintoйtheйpipe.
4. Reinstallйtheйsensorйinйtheйpipe,йandйinйdoingйsoйmakeйsureйthatйtheйsealйisйcleanйand
inйtheйrightйposition.
• Ifйthin-walledйpipesйcarryingйfoodйareйweldedйcorrectly,йtheйsealйisйnotйdamagedйby
theйheatйevenйwhenйmounted.йNeverthelessйitйisйadvisableйtoйremoveйtheйsensorйand
seal.
• Itйmustйbeйpossibleйtoйopenйtheйpipeйbyйapprox.й8йmmйс0.31йin)йinйtotalйtoйpermit
disassembly.
Cleaning with pigs
Itйisйessentialйtoйtakeйtheйinternalйdiametersйofйtheйmeasuringйtubeйandйprocessйconnection
intoйaccountйwhenйcleaningйwithйpigs.йAllйtheйdimensionsйandйlengthsйofйtheйsensorйand
transmitterйareйprovidedйinйtheйseparateй"TechnicalйInformation"йdocument.
Mounting the seals
Complyйwithйtheйfollowingйinstructionsйwhenйinstallingйseals:
• Whenйmountingйtheйprocessйconnections,йmakeйsureйthatйtheйsealsйconcernedйareйclean
andйcenteredйcorrectly.
• Inйtheйcaseйofйmetalйprocessйconnections,йtheйscrewsйmustйbeйtightenedйsecurely.йThe
processйconnectionйformsйaйmetalйconnectionйwithйtheйsensor,йwhichйensuresйaйdefined
compressionйofйtheйseal.
• Inйtheйcaseйofйplasticйprocessйconnections,йcomplyйwithйtheйmax.йscrewйtighteningйtorques
forйlubricatedйthreads:й7йNmйс5.2йlbfйft).йInйtheйcaseйofйplasticйflanges,йalwaysйinsertйa
sealйbetweenйtheйconnectionйandйtheйcounterflange.
• Dependingйonйtheйapplicationйtheйsealsйshouldйbeйreplacedйperiodically,йparticularlyйif
moldedйsealsйareйusedйсasepticйversion)кйTheйintervalйbetweenйchangesйdependsйonйthe
frequencyйofйtheйcleaningйcycles,йtheйcleaningйtemperatureйandйtheйmediumйtemperature.
Replacementйsealsйcanйbeйorderedйasйanйaccessoryйсййй101).
Mounting grounding rings (DN 2 to 25 (1/12 to 1"))
Payйattentionйtoйtheйinformationйonйpotentialйequalizationйсййй31).
Inйtheйcaseйofйplasticйprocessйconnectionsйсe.g.йflangeйconnectionsйorйadhesiveйfittings),
additionalйgroundйringsйmustйbeйusedйtoйensureйtheйpotentialйbetweenйtheйsensorйandйfluid
isйmatched.йIfйgroundingйringsйareйnotйinstalled,йthisйcanйaffectйtheйmeasuringйaccuracyйor
causeйtheйdestructionйofйtheйsensorйasйaйresultйofйtheйelectrochemicalйdecompositionйofйthe
electrodes.
• Dependingйonйtheйoptionйordered,йplasticйdisksйareйusedйinsteadйofйgroundingйrings
onйsomeйprocessйconnections.йTheseйplasticйdisksйonlyйactйasй"spacers"йandйdoйnot
haveйanyйpotentialйmatchingйfunction.йFurthermore,йtheyйalsoйperformйaйsignificant
sealingйfunctionйatйtheйsensor/processйconnectionйinterface.йTherefore,йinйtheйcase
ofйprocessйconnectionsйwithoutйmetalйgroundingйrings,йtheseйplasticйdisks/seals
shouldйneverйbeйremovedйandйshouldйalwaysйbeйinstalledк
• GroundingйringsйcanйbeйorderedйseparatelyйasйanйaccessoryйfromйEndress+Hauser
сййй101).йWhenйorderingйmakeйsureйthatйtheйgroundingйringsйareйcompatible
withйtheйmaterialйusedйforйtheйelectrodes,йasйotherwiseйthereйisйtheйdangerйthatйthe
electrodesйcouldйbeйdestroyedйbyйelectrochemicalйcorrosionк
Materialйspecificationsйсййй96).
• Groundingйrings,йincludingйseals,йareйmountedйinsideйtheйprocessйconnections.
Thereforeйtheйinstallationйlengthйisйnotйaffected.
