ProlineйPromagйHй100йEtherNet/IP Operationйoptions
Endress+Hauser 41
8.3.5 User interface
2 4
6 5
1 32 4
6 5
1 32 4
6 5
1 32 4
6 5
1 32 4
6 5
1 3
ййA0017757-EN
1
2
3
4
5
6
Picture of device
Function row with 6 functions
Device tag
Header
Working area
Navigation area
Header
Theйfollowingйinformationйappearsйinйtheйheader:
• Deviceйtagйсййй48)
• Deviceйstatusйwithйstatusйsignalйсййй69)
• Currentйmeasuredйvaluesйсййй64)
Function row
Functions Meaning
Measuredйvalues Theйmeasuredйvaluesйofйtheйdeviceйareйdisplayed
Menu Accessйtoйtheйoperatingйmenuйstructureйofйtheйdevice,йsameйasйforйtheйoperatingйtool
Deviceйstatus Displaysйtheйdiagnosticйmessagesйcurrentlyйpending,йlistedйinйorderйofйpriority
Dataйmanagement
• DataйexchangeйbetweenйPCйandйmeasuringйdevice:
– UploadйtheйconfigurationйfromйtheйdeviceйсXMLйformat,йcreateйconfigurationйback-up)
– SaveйtheйconfigurationйtoйtheйdeviceйсXMLйformat,йrestoreйconfiguration)
– Exportйtheйeventйlistйс.csvйfile)
– Exportйparameterйsettingsйс.csvйfile,йcreateйdocumentationйofйtheйmeasuringйpoint
configuration)
– ExportйtheйHeartbeatйverificationйlogйсPDFйfile,йonlyйavailableйwithйtheй"Heartbeat
Verification"йapplicationйpackage)
• Uploadйtheйdeviceйdriverйforйsystemйintegrationйfromйtheйdevice
Network
configuration
Configurationйandйcheckingйofйallйtheйparametersйrequiredйforйestablishingйtheйconnection
toйtheйdevice:
• Networkйsettingsйсe.g.йIPйaddress,йMACйaddress)
• Deviceйinformationйсe.g.йserialйnumber,йfirmwareйversion)
Logout Endйtheйoperationйandйcallйupйtheйloginйpage
Navigation area
Ifйaйfunctionйisйselectedйinйtheйfunctionйbar,йtheйsubmenusйofйtheйfunctionйopenйinйthe
navigationйarea.йTheйuserйcanйnowйnavigateйthroughйtheйmenuйstructure.
