ProlineйPromagйHй100йEtherNet/IP Electricalйconnection
Endress+Hauser 27
7 Electrical connection
Theйmeasuringйdeviceйdoesйnotйhaveйanйinternalйcircuitйbreaker.йForйthisйreason,
assignйtheйmeasuringйdeviceйaйswitchйorйpower-circuitйbreakerйsoйthatйtheйpower
supplyйlineйcanйbeйeasilyйdisconnectedйfromйtheйmains.
7.1 Connection conditions
7.1.1 Required tools
• Forйcableйentries:йUseйcorrespondingйtools
• Forйsecuringйclampйсonйaluminumйhousing):йAllenйscrew3йmm
• Forйsecuringйscrewйсforйstainlessйsteelйhousing):йopen-endedйwrenchй8йmm
• Wireйstripper
• Whenйusingйstrandedйcables:йcrimpingйtoolйforйferrule
7.1.2 Requirements for connecting cable
Theйconnectingйcablesйprovidedйbyйtheйcustomerйmustйfulfillйtheйfollowingйrequirements.
Electrical safety
Inйaccordanceйwithйapplicableйfederal/nationalйregulations.
Permitted temperature range
• –40й°Cйс–40й°F)йtoй+80й°Cйс+176й°F)
• Minimumйrequirement:йcableйtemperatureйrangeй≥йambientйtemperatureй+20йK
Power supply cable
Standardйinstallationйcableйisйsufficient.
Signal cable
EtherNet/IP
TheйstandardйANSI/TIA/EIA-568-B.2йAnnexйspecifiesйCATй5йasйtheйminimumйcategoryйfor
aйcableйusedйforйEtherNet/IP.йCATй5eйandйCATй6йareйrecommended.
ForйmoreйinformationйonйplanningйandйinstallingйEtherNet/IPйnetworks,йpleaseйrefer
toйtheй"MediaйPlanningйandйInstallationйManual.йEtherNet/IP"йofйtheйODVA
Organization.
Cable diameter
• Cableйglandsйsupplied:
M20й×й1.5йwithйcableй6йtoй12йmmйс0.24йtoй0.47йin)
• Springйterminals:
Wireйcross-sectionsй0.5йtoй2.5йmm
2
йс20йtoй14йAWG)
