Electricalйconnection ProlineйPromagйHй100йEtherNet/IP
30 Endress+Hauser
1 2 1 2 3 4
A B C
ййA0016924
 9 Device versions and connection versions
A Housing version: compact, aluminum coated
B Housing version: compact hygienic, stainless
1 Cable entry or device plug for signal transmission
2 Cable entry or device plug for supply voltage
C Housing version: ultra-compact hygienic, stainless, M12 device plug
3 Device plug for signal transmission
4 Device plug for supply voltage
10 (0.4)
mm (in)
1 2
3
2
1
2
1
2
3
8 mm
3 mm
8 mm
ййA0017844
 10 Device versions with connection examples
1 Cable
2 Device plug for signal transmission
3 Device plug for supply voltage
Forйdeviceйversionйwithйdeviceйplug:йonlyйpayйattentionйtoйStepй6.
1. Dependingйonйtheйhousingйversion,йloosenйtheйsecuringйclampйorйfixingйscrewйofйthe
housingйcover.
