Mounting ProlineйPromagйHй100йEtherNet/IP
18 Endress+Hauser
h
2
1
ййA0017064
 4 Installation in a down pipe
1 Vent valve
2 Pipe siphon
h Length of down pipe
Installation in partially filled pipes
Aйpartiallyйfilledйpipeйwithйaйgradientйnecessitatesйaйdrain-typeйconfiguration.йTheйempty
pipeйdetectionйсEPD)йfunctionйoffersйadditionalйprotectionйbyйdetectingйemptyйorйpartially
filledйpipes.
³ 5 × DN
³ 2 × DN
ййA0017063
Orientation
Theйdirectionйofйtheйarrowйonйtheйsensorйnameplateйhelpsйyouйtoйinstallйtheйsensor
accordingйtoйtheйflowйdirectionйсdirectionйofйmediumйflowйthroughйtheйpiping).
Anйoptimumйorientationйpositionйhelpsйavoidйgasйandйairйaccumulationsйandйdepositsйin
theйmeasuringйtube.
Theйmeasuringйdeviceйalsoйoffersйtheйemptyйpipeйdetectionйfunctionйtoйdetectйpartiallyйfilled
measuringйpipesйinйtheйeventйofйoutgassingйfluidsйorйvariableйprocessйpressures.
Vertical
ййA0015591
Thisйisйtheйoptimumйforйself-emptyingйpipingйsystemsйandйforйuseйinйconjunctionйwith
emptyйpipeйdetection.
