Endress+Hauser Proline Promag H 100 EtherNet/IP User Manual

Mounting ProlineйPromagйHй100йEtherNet/IP
20 Endress+Hauser
Temperature tables
SI units
T
a
[°C]
T6
[85 °C]
T5
[100 °C]
T4
[135 °C]
T3
[200 °C]
T2
[300 °C]
T1
[450 °C]
30 50 95 130 150 150 150
50 – 95 130 150 150 150
60 – 95 110 110 110 110
US units
T
a
[°F]
T6
[185 °F]
T5
[212 °F]
T4
[275 °F]
T3
[392 °F]
T2
[572 °F]
T1
[842 °F]
86 122 203 266 302 302 302
122 – 203 266 302 302 302
140 – 203 230 230 230 230
System pressure
ййA0015594
Neverйinstallйtheйsensorйonйtheйpumpйsuctionйsideйinйorderйtoйavoidйtheйriskйofйlowйpressure,
andйthusйdamageйtoйtheйliner.
Furthermore,йinstallйpulseйdampersйifйreciprocating,йdiaphragmйorйperistalticйpumps
areйused.
• Forйinformationйonйtheйlinerрsйresistanceйtoйpartialйvacuumйсййй93)
• Informationйonйtheйshockйresistanceйofйtheйmeasuringйsystemйсййй92)
• Informationйonйtheйvibrationйresistanceйofйtheйmeasuringйsystemйсййй92)
Vibrations
Inйtheйeventйofйveryйstrongйvibrations,йtheйpipeйandйsensorйmustйbeйsupportedйandйfixed.
Informationйonйtheйshockйresistanceйofйtheйmeasuringйsystemйсййй92)
Informationйonйtheйvibrationйresistanceйofйtheйmeasuringйsystemйсййй92)
L
ййA0016266
 5 Measures to avoid device vibrations (L > 10 m (33 ft))
