Endress+Hauser Proline Promag H 100 EtherNet/IP User Manual

Commissioning ProlineйPromagйHй100йEtherNet/IP
58 Endress+Hauser
Parameter overview with brief description
Parameter Description Selection / User entry Factory setting
Formatйdisplay Selectйhowйmeasuredйvaluesйareйshownйon
theйdisplay.
• 1йvalue,йmax.йsize
• 1йbargraphй+й1йvalue
• 2йvalues
• 1йvalueйlargeй+й2йvalues
• 4йvalues
1йvalue,йmax.йsize
Valueй1йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
• Volumeйflow
• Massйflow
• Correctedйvolumeйflow
• Flowйvelocity
• Conductivity
• Correctedйconductivity
• Totalizerй1
• Totalizerй2
• Totalizerй3
• None
Volumeйflow
0%йbargraphйvalueй1 Enterй0%йvalueйforйbarйgraphйdisplay. Signedйfloating-pointйnumber 0йl/h
100%йbargraphйvalueй1 Enterй100%йvalueйforйbarйgraphйdisplay. Signedйfloating-pointйnumber 0.025йl/h
Decimalйplacesй1 Selectйtheйnumberйofйdecimalйplacesйforйthe
displayйvalue.
• x
• x.x
• x.xx
• x.xxx
• x.xxxx
x.xx
Valueй2йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
Picklistйсseeй1stйdisplayйvalue) None
Decimalйplacesй2 Selectйtheйnumberйofйdecimalйplacesйforйthe
displayйvalue.
• x
• x.x
• x.xx
• x.xxx
• x.xxxx
x.xx
Valueй3йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
Picklistйсseeй1stйdisplayйvalue) None
0%йbargraphйvalueй3 Enterй0%йvalueйforйbarйgraphйdisplay. Signedйfloating-pointйnumber 0
100%йbargraphйvalueй3 Enterй100%йvalueйforйbarйgraphйdisplay. Signedйfloating-pointйnumber 0
Decimalйplacesй3 Selectйtheйnumberйofйdecimalйplacesйforйthe
displayйvalue.
• x
• x.x
• x.xx
• x.xxx
• x.xxxx
x.xx
Valueй4йdisplay Selectйtheйmeasuredйvalueйthatйisйshownйon
theйlocalйdisplay.
Picklistйсseeй1stйdisplayйvalue) None
Decimalйplacesй4 Selectйtheйnumberйofйdecimalйplacesйforйthe
displayйvalue.
• x
• x.x
• x.xx
• x.xxx
• x.xxxx
x.xx
