PROline Prosonic Flow 93 FOUNDATION Fieldbus 4 Analog Input function block
Endress+Hauser 171
CHANNEL OOS Assignment of the output values (process variables) of the
Transducer Blocks “TRANSDUCER_CH1” (flow channel 1, base
index 1200), “TRANSDUCER_CH 2” (flow channel 2, base index
1300) or “TRANSDUCER_TOT” (totalizer, base index 1550) to the
input of the Analog Input function block in question. The
Transducer Block of makes eight process variables available to the
input channels of the Analog Input function blocks:
User input:
2 = Volume flow channel 1
7 = Totalizer 1
8 = Totalizer 2
9 = Totalizer 3
20 = Volume flow channel 2
21 = Sound velocity channel 1
22 = Sound velocity channel 2
23 = Flow velocity channel 1
24 = Flow velocity channel 2
25 = Average volume flow
26 = Volume flow sum
27 = Volume flow difference
28 = Average sound velocity
29 = Average flow velocity
30 = Signal strength channel 1
31 = Signal strength channel 2
Factory setting:
0 = Unitialized
 Note!
If 0 (= Uninitialized) is selected, the operating mode of the function
block does not switch to the AUTO status. In this case, the “BLOCK
CONFIG ERROR” block error is displayed in the BLOCK_ERROR
parameter.
FIELD_VAL read only Displays the input value of “TRANSDUCER_CH1” (flow channel 1,
base index 1200), “TRANSDUCER_CH 2” (flow channel 2, base
index 1300) or “TRANSDUCER_TOT” (totalizer, base index 1550)
including the related status. The value relates to a percentage of
the XD_SCALE input range and when simulation is active is
replaced by the simulation value.
 Note!
The process variables and the input value of the Analog Input
function block are assigned via the CHANNEL parameter.
GRANT_
DENY
AUTO - MAN -
OOS
Releases or restricts the access authorisation of a fieldbus host
system to the field device.
 Note!
This parameter is not evaluated by PROline Prosonic Flow 93
FOUNDATION Fieldbus.
Analog Input function block /
Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630
Parameter Write access
with operating
mode
(MODE_BLK)
Description
FIELD_VAL
100 Process variables PV XD_SCALE_0%
–()⋅
XD_SCALE_100% XD_SCALE_0%–()
-----------------------------------------------------------------------------------------------------------------------------
=
