"Setup" menu → Current output
Parameter overview with brief description
Terminal number
Current output 1 to n
Signal mode
Assign current output 1 to n
Current span
0/4 mA value
20 mA value
Failure mode
Failure current
Fixed current
Parameter Prerequisite Description User Entry Factory Setting
Assign current
output 1 to n
— Select process variable
for current output.
•Off —
Terminal number — Shows the terminal
numbers used by the
current output module.
•Not used
• 24-25 (I/O 2)
• 22-23 (I/O 3)
—
Current span — Select current range
for process value out-
put and upper/lower
level for alarm signal.
• 4...20 mA
NAMUR
• 4...20 mA US
• 4...20 mA
• 0...20 mA
• Fixed current
Approval specific:
• 4...20 mA NAMUR
• 4...20 mA US
Signal mode — Select the signal mode
for the current output.
• Passive
•Active
Passive
