J22 TDLAS Gas Analyzer 4900002277
SpectraSensors, Inc. 59
Displaying the I/O configuration
The I/O configuration submenu guides the user systematically through all the
parameters in which the configuration of the I/O modules is displayed.
Navigation
"Setup" menu → I/O configuration
Parameter overview with brief description
Failure mode Select measured value output
behavior when a diagnostic mes-
sage occurs via Modbus communi-
cation.
NaN
1)
— —
1) Not a Number
Parameter Description User Entry Factory Setting
I/O module 1 to n terminal numbers
I/O Communication
I/O module 1 to n information
I/O module 1 to n type
Apply I/O configuration
Conversion code
Parameter Description User Entry Factory Setting
I/O module 1 to n ter-
minal numbers
Shows the terminal numbers used
by the I/O module.
•Not used
• 26-27 (I/O 1)
• 24-25 (I/O 2)
1)
• 22-23 (I/O 3)
1)
—
I/O module 1 to n infor-
mation
Shows information of the plugged
I/O module.
• Not plugged
•Invalid
•Not configurable
• Configurable
—
I/O module 1 to n type Shows the I/O module type. • Off
•Current output
2)
•Switch output
2)
—
