J22 TDLAS Gas Analyzer 4900002277
SpectraSensors, Inc. 123
Parameter overview with brief description
Diagnostic List Up to 5 currently pending diagnostic events can be displayed in the Diagnostic list
submenu along with the associated diagnostic information. If more than 5
diagnostic events are pending, the events with the highest priority are shown on
the display.
Navigation
Diagnostics → Diagnostic list
A0014006-EN
2: Diagnostict list local display example
Operating time from restart
Operating time
Parameter Prerequisite Description User Interface
Actual diagnostics A diagnostic event
has occurred.
Shows the current occured diagnostic
event along with its diagnostic infor-
mation.
If two or more messages
occur simultaneously, the
message with the highest
priority is shown on the
display.
Symbol for diagnostic behav-
ior, diagnostic code and short
message.
Previous diagnos-
tics
Two diagnostic
events have already
occurred.
Shows the diagnostic event that
occurred prior to the current diag-
nostic event along with its diagnostic
information.
Symbol for diagnostic behav-
ior, diagnostic code and short
message.
Operating time
from restart
— Shows the time the device has been
in operation since the last device
restart.
Days (d), hours (h), minutes
(m) and seconds (s)
Operating time — Indicates how long the device has
been in operation.
Days (d), hours (h), minutes
(m) and seconds (s)
