4900002277 J22 TDLAS Gas Analyzer
66 SpectraSensors, Inc.
Configuring the local display
The Display wizard guides you systematically through all the parameters that can
configured for configuring the local display.
Navigation
"Setup" menu → Display
Assign diagnostic
behavior
In the Relay output
function parameter,
the Diagnostic
behavior option is
selected.
Select diagnostic
behavior for switch
output.
•Alarm
•Alarm or
warning
• Warning
Alarm
Assign status In the Relay output
function parameter,
the Digital Output
option is selected.
Select device status for
switch output.
—Off
Switch-off value In the Relay output
function parameter,
the Limit option is
selected.
Enter measured value
for the switch-off
point.
Signed floating-
point number
0 ppmv
Switch-off delay In the Relay output
function parameter,
the Limit option is
selected.
Define delay for the
switch-off of status
output.
0.0 to 100.0 s 0.0 s
Switch-on value In the Relay output
function parameter,
the Limit option is
selected.
Enter measured value
for the switch-on
point.
Signed floating-
point number
0 ppmv
Switch-on delay In the Relay output
function parameter,
the Limit option is
selected.
Define delay for the
switch-on of status
output.
0.0 to 100.0 s 0.0 s
Failure mode — Define output behavior
in alarm condition.
• Actual status
•Open
•Closed
Open
Parameter Prerequisite Description User Entry Factory Setting
Format display
Display
Value 1 display
0% bargraph value 1
